Unifiltech unique manufacturing process of Resin-Pure filter elements produces a rigid fixed-matrix structure with true graded-porosity. This maximizes contaminant-holding capacity while preventing the unloading behavior that is often problematic in competitive products. The grooved outer surface greatly expands the filter’s effective surface area and further increases the contaminant holding capacity. The synthetic fiber/phenolic resin binder offers well- proven performance operating under challenging conditions of high temperatures, high fluid viscosities, and high differential pressures
● Micron ratings from 2 to 150 um
● True graded-porosity structure for high dirt holding
● Broad chemical compatibility
● Rigid construction ideal for high viscosity uses
● High temperature resistance
● Coatings
● Epoxies
● Adhesives
● Sealants
● Hydraulic Fluids
● Lubricating Oils
● Greases
● Paints
● Inks
● Maximum Operating Temperature：121℃ （Standard DOE），149℃（High Temperature DOE ）， 82℃ Polypropylene Spring or Core Extender
● Maximum Operating Differential Pressure：90psid（6.2bar@65℃）
● Recommended Change-out Differential Pressure：35psid
● Outside Diameter：65mm（2.56 inch）
● For detailed applications and filtration products, please contact Unifiltech Technical Supports and Sales Engineers.
